CPU

Intel i3/i5/i7 CPU as option

chipset

CPU Integrated

System Memory

1x DDR3 SO-DIMM 4G,  up to 8GB  （default 4GB)

Storage

128G SSD or 320G HDD /500G HDD  (default 64GB SSD)

LAN

RealTek 8111E Gigabit Ethernet

Audio

RealTek  ALC661 HD  audio decode

LCD screen

LCD size

15.6 inch

Touch screen

Capacitive touch ,USB interface

Resolution

1366*768  , 1920*1080(FHD ) as option

Brightness

300cd /㎡

Response

10ms

Tilting Angle

0-90 degrees

I/O ports

Serial ports

1*DB9 (COM1，COM2) DC5V/12V jumper optional on PIN1

USB

1*USB 3.0    5 *USB 2.0

Ethernet

2*RJ45 10/100Mbps

VGA

1*DB15 2nd display VGA connector

Audio

1*line out   1*Mic in

DC port

1*12V/5A  DC input for pos power source

Relative Humidity

20﹪~80﹪ Non-condensing

Operating Temperature

0 ℃ to 40℃

input

100V-240V,50-60HZ 1.5A

output

DC 12V/5A

Color

black

Packing dimension

450*290*430mm

Package: carton box with Foam packaging

NW:5.5KG    GW:7KG

Customer display(VFD or LCD), MSR ,WIFI
