Panel type

15inch LED panel

Resolution

XGA 1024*768 @ 75Hz

Display area

304.1(H)×228.1(V) mm

Contrast

700:1

View Angle

Horizontal：160；Vertical：160

Display color

16.2M

Brightness

350nits

Backlight Lifetime

5000 hours

Reponse  time

10ms

Control Panel

Power, auto adjust, menu, up, down,

Environmental

Relative Humidity

10﹪~90﹪@ 40℃  Non-condensing

Operating Temperature

-20 ℃ to  60℃

Storage Temperature

-30 ℃ to  70℃

Vibration

1G peak,5-500Hz(Rondom)

Shock

15G peal Acceleration (11 msec.duration)

Rating

Facilitate Installation of the Demolition

Touch panel

Type

Projective multiple point capacitive touch

Resolution

4096*4096

Transmittance

87+/-2%

interface

USB touch

Mechanical

Material

High Strength cold Rolling steel chassis

mounting

Left/Right M4.5 holes, supporting Embedded Mounting

Dimension

351.2(W)*275.2(H)*45(D)

Power

Power Input

DC12V/3A,DC Jack 2.0mm

Power Consumption

40W Max
