Panel type

10.1 inch LCD panel

Resolution

1280*800 @ 60Hz

Display area

216.96(H)×136.5(V) mm

Contrast

800:1

View Angle

Horizontal：170；Vertical：170

Display color

16.2M

Brightness

350nits （1000nits as option)

Backlight Lifetime

30,000 hours

Control Panel

Power, auto adjust, menu, up, down,

Environmental

Relative Humidity

10﹪~90﹪@ 40℃  Non-condensing

Operating Temperature

-20 ℃ to  60℃

Storage Temperature

-30 ℃ to  70℃

Vibration

1G peak,5-500Hz(Rondom)

Shock

15G peal Acceleration (11 msec.duration)

Rating

Facilitate Installation of the Demolition

Touch panel

Type

Projective capacitive touch or 5-wire resistive touch

Resolution

4096*4096

Transmittance

87+/-2%

interface

USB touch

Mechanical

Material

High Strength cold Rolling stell chassis

mounting

Top/Bottom and Left/Right M3 M4 holes, VESA75*75mm mount

 supporting Embedded Mounting

Dimesion

248(W)*190(H)*38(D)

Power

Power Input

DC12V/3A ,DC Jack 2.0mm

Power Consumption

40W Max
