Technical Information：

ITCF405 5B8C metal cash drawer for POS system solution

Model:  ITCF-405

Dimension: 410W×415L×100H (mm)

Single front slot for check, credit card and bills

Different panels can be customized

Available in black/white

5bills/5coins or 5 bills/8 coins /10 bills/7bills 3coins

Fast open with heavy-duty ball bearing rollers

Fixed bill divider, removable coin tray

9-24V compatible

3-position key lock with 100 key combinations

RJ11 interface as standard, USB optional

Item Specification

Physical Dimension 410W×415L×100H(mm)

Packing Dimension 475W×455L×165H(mm)

Cash Tray Dimension 355W×331L×65H(mm)

Bill Tray Dimension 355W×180L×65H(mm)

Coin Tray Dimension 355W×145L×70H(mm)

Weight Net weight:5.5kg , Gross weight:6.5kg

Color Black/White/Custom type

Bill Tray/ Coin Tray 5 Bill+8 Coin / 5 Bill+5Coin / 10Bill/7 Bill+3Coin

 Fixed Bill Dividers and Removable Coin Case

Inner Drawer Plastic Drawer

Bill holders Metal Wire Gripper

Panel Different panels can be customized

Dividers Vertical Plastic Divider

Rollers Heavy Duty Plastic Rollers

Key Lock Three-position Key Lock with 10~100 Key Combinations

Media Slot Single Media Slot

Micro Switch/Sensor Open By Driver Signal To The Solenoid(option)

I/O Interface RJ11 as Standard,USB for option

Cable Connection External Cable on Bottom

Cable Lengths 1.5 Meters

Durability 1,000,000 Cycles
