Print Method

Direct Thermal

Print Speed

260mm/s

Resolution

576dots/line or 572dots/line

Printing Width

72mm

Paper separator(option)

48mm/52mm/56mm/64mm/68mm/76mm/80mm

Interface

RS232C+USB+Lan

Kitchen function

Power,Paper,Erro

Support

LED light with beeper

Without

Hanging device

Equipped

Memory

Input buffer

256kbytes

NV Flash

256kbytes

Fonts

Font A

12x24

Font B

9x17

Fonts

Chinese

GB18030,BIG5 24x24dots

Japanese/Korea

Support

User-defined

Support

Barcode

1D

 UPC-A/UPC-E/JAN13（EAN13）/JAN8（EAN8）/CODE39/ITF/CODABAR/CODE93/CODE128

2D

QR code

Detection

Sensors

Paper out, paper near end, cover open, cutter jam,paper jam and black mark detection(Optional)

Power Supply

Input

AC 100V-240V 50/60HZ

DC 24V/2.5A

DC 24V/2.5A

Paper

Paper Type

Thermal Receipt Paper

Paper Width

48mm/52mm/56mm/64mm/68mm/76mm/80mm

Paper Thickness

0.06~0.08mm
