Technical Information:
AI cloud function, android POS software for food and retail , cash register cheaper price POS solution
Updated function
1.relating also “XML”, using pixel.
2. Adjustable KB size( 4 x 16 instead of 4 x 8) , and Key# was double up(to 64 keys instead of 32 keys)
3.Table Graphic Mapping and list improved much, including the each table status .... such as ..
4. How many time have been passed, scheduling times & etc.,
5. Menu & Condiment input more convenient
6. R/X/Z/Stock/Customer-modes : improved a lot
7. Store logo(printing on Receipts) can get from Mobile-Camera or folder(Internal memory or external USB disk)
8. PLU/Item-Picture can also get from Camera as well
9. CLOUD function(Dealer option)
Display |
Clerk | 1280X800 10.1”IPS |
Rear/Customerdisplay | 2.8inch.320x240 TFT LCD |
Cash Drawer option |
RJ11 | 420*410*100 5B8C Direct driving. 12VDC as option |
Pinter |
FTP628 compatible | 58mm thermal printer |
Main board |
CPU | RK3288 CPU |
RTC | External rechargeable battery support |
Flash Memory | 8G EMMC |
RAM | 2G DDR3 |
Interface |
Interface | 1*RS232,2*USB,1*ETHENET |
Capability | PC, scanner, scale, kitchen printer |
WIFI | 802.11b/g/n Support |
Power supply |
Power supply | DC12V/4A adaptor |
Rate | AC85~245,50~60HZ |
Power | Approx. 36W |
Temperature and humidity |
Operation | 0-50 ℃ |
Storage | -40~60℃ |
Humidity | 20-90% (Relative) |
Package |
Gross Weight | 4.6Kg |
package | 395x360x350mm |
Shock | 1m drop on concrete surface |
MTBF and standard |
MTBF | MTBF>5000hours |
EMC | Custom |
APK Software
Items | Capability | Description |
Group | 10 | Group 10 is minus |
Department | 64 | Some version support 128 |
PLU | 99999 | Code range from 1-99999 |
PLU price | 3 | 3 prices |
PLU name | 5 | Max. 5 names for each PLU |
Clerk | 50 | 50 clerks, additional 1 supervisor, 1 trainer |
Customer/VIP | -- | can program as many as you want |
% | 3 | discount or service charge |
(+) | 1 |
|
(-) | 1 |
|
EC | 1 |
|
Transaction void | 1 |
|
Refund | 1 |
|
Return merchandise | 1 |
|
Receive on account | 1 |
|
Paid out | 1 |
|
Tips | 1 |
|
Decimals of amount | 0-3 | No decimal or 1-3 decimal |
Decimals of quantity | 0-3 | No decimal or 1-3 decimal |
VAT | 6 |
|
TAX | 6 | Tax1-6 can be combined |
TAX and service | 1 |
|
Media | 9 | Total 9 media type |
Table | 200 | Graphic or list mode support |
K/M | 999 | 1-999 cooking messages |
Condiment group | 10 | 10 condiment groups |
Client | 8 | Max 8 clients, inc. mobile order |
Kitchen printers | 2/8 | Max 8 network type, Max 2 rs232 type |
Journal | * | No limit (base on flash memory) |
